Displaying items by tag: lighting system

Friday, 01 October 2021 07:47

Intensive care and examination rooms

Intensive care is normally the entry point for a critically ill or injured patient into the hospital. Visual examination plays a major role in deciding the right treatment. This demands a high level of general illumination as well as good colour rendering.

Published in Resources
Friday, 01 October 2021 07:47

Cleanroom Lighting Options Explained

Lighting is an often overlooked but critical part of the cleanroom design process. A poorly lit cleanroom makes work difficult, and a cleanroom with energy inefficient lighting is not sustainably designed and increases energy costs. When designing a cleanroom, choosing lighting options that work for your application can also help control contamination and promote temperature control. Here are the cleanroom lighting options explained to help you in your cleanroom design project.

Lighting types

The first lighting option to consider is the type of lighting to use: incandescent, fluorescent, or LED. The chart below briefly explains how each of these types of lighting work, as well as their costs and benefits.

Incandescent Fluorescent LED

Incandescent lightbulbs are the traditional lightbulbs. They contain a capsule inside that holds gas around a wire filament, which went electricity is applied, gives off light. They give off heat as well as light, which makes them an inefficient light source and an energy waster. In fact, incandescent bulbs are banned in several countries. In addition to their inefficiency, the light they give off is often not bright or consistent enough for cleanroom applications.

Fluorescent lights work by ionizing mercury vapor inside a glass tube, which causes the gas’s electrons to emit UV light, which is converted to visible light by the coating of the glass tube. They’re available in the traditional long tubes as well as compact fluorescent lamps (CFLs), which are shaped like incandescent lightbulbs. They are more efficient than incandescent bulbs without being much more expensive and are appropriate for many cleanroom applications.

LED lights, which stands for Light Emitting Diodes, are the most energy-efficient lighting option. They create solid-state lighting by converting electricity directly into light, unlike incandescents and fluorescents. They tend to have a higher initial cost, but their efficiency offsets that cost. LED lighting is often ideal for cleanroom applications, as they do not produce any heat.


Also worth considering is natural lighting—you may want to evaluate whether is it possible and practical to incorporate windows into your cleanroom design. Natural light is free, but windows may come with some inefficiencies in terms of temperature control.

Lighting fixture options

There are a variety of fixture options for cleanroom lighting, including

  • Fluorescent ceiling modules — these fluorescent ceiling modules are similar to what you imagine when you picture fluorescent lights: modules that house long fluorescent light tubes. Modules designed specifically for cleanrooms are dust, corrosion, and water resistant and house up to for T8 light tubes.
  • LED light panels — LED light panels provide bright, optimal lighting for cleanroom spaces, without crevices or seams that can house particulate matter or contaminants.
  • LED light strips — LED strips attach directly to the T-bar of the ceiling grid, keeping them out of the way of ceiling filters and allowing for unobstructed air flow.
  • Teardrop lights — teardrop lights are designed for cleanrooms that require whole-ceiling filter coverage, and they minimize obstruction of airflow by hanging down from the ceiling. These are best in cleanrooms with plenty of overhead space since they do hang down from the ceiling.
  • Flow through modules — flow through lighting modules use fluorescent tube lights that are placed directly under the filter system, without blocking airflow. This is a good option when your application requires efficient use of overhead space.
Published in Resources
Friday, 01 October 2021 07:47

Plan Your Cleanroom Lighting

Lighting is an important consideration at the design phase of a cleanroom and the choices you make should compliment your overall envelope solution. Here we will talk you through some of the options available.

Published in Resources
Friday, 01 October 2021 07:47

Cleanroom Lighting Levels

Everyone knows what watts are, but there are other measurements for lighting, including how much light you need, how intense it should be, and how far you need it to go. These measurements are:

Published in Resources
Friday, 01 October 2021 07:13

The Basics of Cleanroom Lighting

Cleanroom or clean room environments are extremely specialized with requirements for each technology brought into the space. Cleanroom lighting is no exception. But what is a cleanroom?

Published in Resources
Wednesday, 01 July 2015 03:55

Cleanroom lamp types

Lighting systems can utilize a number of different lamp types. Incandescent, high intensity discharge and fluorescent lamps are most commonly used in residential, commercial and industrial facilities. Fluorescent lamps are nearly always used in cleanroom environments due to their energy efficiency, low maintenance and long life.

Published in Resources
